镀锌铁皮制成.
高强度及弯曲性.
遵照国际电工法规350及美国ul标准制作.
耐温范围：-50oc to +300oc.
part no
nominal size iso (mm)
nominal size us (inches)
i.d. (mm)
o.d. (mm)
min. bend radius (mm)
length (m/coil)
fm-10ul 16 3/8" 9.52- 9.96 14.22- 15.49 51 50
fm-11ul 20 1/2" 15.88- 16.38 21.84 - 23.37 76 50
fm-12ul 25 3/4" 20.62-21.21 26.54 - 28.07 102 50
fm-13ul 32 1" 25.40 - 26.42 30.02 - 35.05 127 50
fm-14ul 40 1-1/4" 31.75- 33.02 39.37 - 41.40 159 30
fm-15ul 50 1-1/2" 38.10 - 40.01 46.99- 49.53 190 30
fm-16ul 63 2" 50.80 - 52.83 59.69 - 62.23 254 20
fm-17ul 75 2-1/2" 63.54 72.64 - 77.72 318 15
fm-18ul 90 3" 76.20 85.34- 90.42 381 15
fm-19ul 100 4" 101.60 110.74 - 115.82 508 10
