商品详情
| 法兰外径(D1) | 宽度(b) | 法兰宽度(c) | 基本额定动负荷 Cr(N) | 基本额定静负荷 Cor(N) | 允许回转数 | |||||||
| 内径(d) | 外径(D) | open | zz | open | zz | open | zz | 润滑脂 | 润滑剂 | |||
| *1000rpm | ||||||||||||
| MF52zz | 2 | 5 | 6.2 | 2 | 3 | 0.6 | 0.6 | 169 | 50 | 85 | 100 | |
| MF62zz | 2 | 6 | 7.2 | 2.5 | 3 | 0.6 | - | 330 | 99 | 75 | 90 | |
| MF72zz | 2 | 7 | 8.2 | 2.8 | 3 | 0.6 | 0.6 | 386 | 129 | 63 | 75 | |
| MF82X | 3 | 8 | 9.2 | 2.5 | - | 0.6 | - | 558 | 180 | 60 | 67 | |
| MF63zz | 3 | 6 | 7.2 | 2 | 3 | 0.6 | 0.6 | 209 | 74 | 71 | 80 | |
| MF83zz | 3 | 8 | 9.2 | 2.5 | 3 | 0.6 | - | 395 | 141 | 60 | 67 | |
| MF93zz | 3 | 9 | 10 | 11 | 2.5 | 4 | 0.6 | 0.8 | 571 | 189 | 56 | 67 |
| MF74zz | 4 | 7 | 8.2 | 2 | 3 | 0.6 | 0.6 | 255 | 108 | 60 | 67 | |
| MF84zz | 4 | 8 | 9.2 | 2 | 3 | 0.6 | 0.6 | 395 | 141 | 56 | 67 | |
| MF104zz | 4 | 10 | 11 | 12 | 3 | 4 | 0.6 | 0.8 | 711 | 272 | 48 | 56 |
| MF85zz | 5 | 8 | 9.2 | 2 | 3 | 0.6 | 0.6 | 218 | 90 | 53 | 63 | |
| MF95zz | 5 | 9 | 10.2 | 2.5 | 3 | 0.6 | 0.6 | 431 | 169 | 50 | 60 | |
| MF105zz | 5 | 10 | 11 | 12 | 3 | 4 | 0.6 | 0.8 | 431 | 169 | 50 | 60 |
| MF115zz | 5 | 11 | 12.5 | - | 4 | 0.8 | 1 | 716 | 282 | 45 | 53 | |
| MF106zz | 6 | 10 | 11.2 | 2.5 | 3 | 0.6 | 0.6 | 496 | 218 | 45 | 53 | |
| MF126zz | 6 | 12 | 13 | 14 | 3 | 4 | 0.6 | 0.8 | 716 | 295 | 43 | 50 |
| MF117zz | 7 | 11 | 12.2 | 2.5 | 3 | 0.6 | 0.6 | 455 | 202 | 43 | 50 | |
| MF137zz | 7 | 13 | 14 | 15 | 3 | 4 | 0.6 | 0.8 | 541 | 276 | 40 | 48 |
| MF128zz | 8 | 12 | 13 | 14 | 2.5 | 4 | 0.6 | 0.8 | 543 | 274 | 40 | 48 |
| MF148zz | 8 | 14 | 15.6 | 3.5 | 4 | 0.8 | 0.8 | 817 | 386 | 38 | 45 | |
